UAV Type
Multirotor, 4 electric motors
Life cycle stage
Serial production
Launch/takeoff method
Vertical
Minimum takeoff and landing area
2.5 m × 2.5 m
Required landing surface type
Unprepared level surface
Warranty period
12 months or 100 takeoff-landing cycles
Compliance with RF Government Decree No. 1701 dated 30.11.2024
Compliant
Weight (without batteries)
9.9 kg
Payload capacity
Up to 12 kg
Maximum takeoff weight
23.5 kg
Communication link range
Up to 20 km (depending on conditions and configuration)
Communication link frequency range
5.150–5.850 GHz or 2.4015–2.4815 GHz and 5.725–5.850 GHz
Batteries (capacity)
4 × 22.2 V, 16,000 mAh
Communication interfaces
Radio, Galileo, BeiDou, GPS and GLONASS
GNSS parameters
GPS, GLONASS, positioning accuracy 2.5 m, maximum coordinate update rate 500 m/s
Radio communication parameters
Frequency range: 5.725–5.850 GHz, output power 25 mW
Maximum flight altitude
Up to 1,000 m
Flight duration without payload
Up to 52 minutes (depending on conditions and configuration)
Flight duration with payload
23 minutes
Supply voltage
39.6–50.4 V
Maximum flight speed
22 m/s
Video camera specifications
3-axis stabilized gimbal. Recording resolution: 2560×1440 px. Display resolution on controller: 1920×1080. Optical zoom: 10×. Hybrid zoom: 30×
Permissible ambient temperature
−20 to +40 °C
Maximum wind speed
10 m/s
Additional restrictions
Flights to be conducted under normal climatic conditions in accordance with GOST R 15150-69
